RHYTHM • MANUAL

Quickstart Guide Pattern Track Mixer Song Scope Sample Pool Calculator Settings

Power on. Make a beat. Save something real.

RHYTHM is a compact hardware groovebox for building beats, patterns, and song ideas fast with a tactile, hands-on workflow. This guide is tuned for a first successful session: power on, load sounds, program a pattern, build a variation, chain it into a song, and save your work.

First-run goal: By the end of this guide, a new user should be able to create a session, load sounds, start playback, program a simple pattern, add variation, chain patterns into a song, and save.

Before You Start

What you need

  • RHYTHM with included Micro SD card with samples
  • USB-C power
  • Headphones, speakers, or a mixer connected to audio out
Placeholder image for RHYTHM front view and connections.
Suggested final image: front/top product view with power, audio, and SD locations called out.

Getting Familiar with RHYTHM

Display

  • Mode name and view name
  • Play/Stop indicator
  • Current Pattern (example: P01)
  • Sequencer position
  • Parameters for the current view
  • Current Track (example: T1)
  • BPM

Transport

  • Left and Right move through views
  • Hold Function + Left = Play / Stop
  • Hold Function + Right = Select Pattern with Button Grid

Button Grid

  • Buttons serve different purposes depending on the current mode
Placeholder image for RHYTHM display and controls overview.
Suggested final image: labeled screenshot or annotated device photo showing display zones and core controls.

Power On

  1. Connect audio out to headphones, speakers, or a mixer.
  2. Connect USB-C power.
  3. Turn RHYTHM on with the power switch on the left side.

When startup completes, RHYTHM opens in Pattern mode, Grid view, and is ready to use.

Moving around the user interface

  • Press Left or Right to cycle through views in the current mode.
  • Hold Function and press grid buttons 1-8 to select tracks.
  • Hold Function and press grid buttons 9-16 to change modes.
  • The Encoder can edit values, scroll views, and confirm actions.

Editing values

  • Turn the encoder to move through the parameters shown on the right side of the screen.
  • Press the encoder to select a parameter.
  • Turn the encoder to change the selected value.
  • Press the encoder again to deselect it.

Step 1 — Create a New Session

  1. Hold Function and press the SESS (Session) button.
  2. Press Right until you reach SESSION FILE view.
  3. Use the encoder to select NEW and press the encoder.
  4. Confirm YES.
Placeholder screenshot for session file new flow.

Make Your First Pattern

Step 2 — Load Sound

  1. Hold Function and press the SMPL (Sample Pool) button.
  2. Use Left / Right buttons to select your sample slot (1-32).
  3. Use Encoder to select LOAD and press the encoder.
  4. Use Encoder to scroll through the sample list.
  5. Press Encoder to load / preview a sample or open a folder.
  6. Select [BACK] if needed and then [EXIT] to complete the loading process.
Placeholder screenshot for sample pool load screen.

Step 3 — Select a track and choose a sound

  1. Hold Function and press the TRCK (Track) button.
  2. Hold Function and press one of track buttons T1-T8 to select a track.
  3. Use Left / Right to go to the TRACK ENGINE view.
  4. Use the encoder to select SND.
  5. Press the Encoder to change the SND value to the sound you want.

Step 4 — Start the Sequencer

  1. Hold Function and press the Left / Play transport button.

Step 5 — Program a Pattern

  1. Hold Function and press the PTRN (Pattern) button.
  2. Hold Function and press one of track buttons T1-T8 to select the track you want to program.
  3. Use Left / Right to select Grid view.
  4. Press grid buttons to add or remove notes.
  5. Adjust note, velocity, and length with the Encoder.
Repeat steps 2 through 5 for each sound you want to add.
Placeholder screenshot for grid view with active steps.

Choose Another Pattern

  1. Hold Function and press the Right / Pattern transport button.
  2. The Button Grid will indicate what Pattern is currently selected.
  3. Select grid buttons 1-16 to choose a different pattern.
Repeat the programming step for each sound you want to add to the chosen pattern.

Build a Simple Song Chain

  1. Hold Function and press the SONG button to enter Song mode.
  2. Press Left to switch the sequencer play mode between PTN and SNG.
  3. Set the play mode to SNG.
  4. Use the encoder to scroll through song steps.
  5. For each song step, choose which pattern should play there by holding Function + Right / Pattern and pressing the Grid button of the pattern you want.

Song mode basics

  • In SNG mode, RHYTHM plays song steps in sequence.
  • Press Right to toggle loop ON or OFF.
  • The end of the song is the first step without a pattern assigned.
  • If loop is ON, the song repeats.
  • If loop is OFF, playback stops at the end.
  • Grid buttons 1-8 control song-step track on/off.
  • Grid buttons 9-16 control mutes.
Placeholder screenshot for song mode chain view.

Save Your Session

  1. Hold Function and press the SESS (Session) button.
  2. Press Left or Right until you reach FILE.
  3. Use the encoder to choose SAVE.
  4. Press the encoder to open name entry.
  5. Enter a name by selecting characters.
  6. Choose SAVE and press Encoder.

Load a Session

  1. Hold Function and press the SESS (Session) button.
  2. Press Left or Right until you reach FILE.
  3. Choose OPEN.
  4. Use the encoder to select a saved session.
  5. Press the encoder to load it.
If you power off without saving, unsaved changes are lost.

Troubleshooting

  • No sound: Confirm audio is connected.
  • Sample track silent: Confirm the Micro SD card is inserted and samples are loaded in Sample Pool.
  • Song playback not changing step: Confirm the play mode is set to SNG instead of PTN.
  • Work disappeared: Save the session before powering off.

Support

Web: https://zeroneng.com

Discord: https://discord.gg/RzFStZty4

Pattern Mode

Reference page for RHYTHM pattern mode with five placeholder view sections ready for screenshots, instructions, and notes.

Views

This page covers Pattern mode. Use the view anchors below to jump directly to the section you want to document.

Pattern — View 1

Placeholder Pattern mode screen image for view 1.
Replace this with a real 128x64 screenshot for Pattern mode, View 1.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Pattern — View 2

Placeholder Pattern mode screen image for view 2.
Replace this with a real 128x64 screenshot for Pattern mode, View 2.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Pattern — View 3

Placeholder Pattern mode screen image for view 3.
Replace this with a real 128x64 screenshot for Pattern mode, View 3.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Pattern — View 4

Placeholder Pattern mode screen image for view 4.
Replace this with a real 128x64 screenshot for Pattern mode, View 4.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Pattern — View 5

Placeholder Pattern mode screen image for view 5.
Replace this with a real 128x64 screenshot for Pattern mode, View 5.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Replace placeholder screen images in the shared images/ folder as real screenshots become available.

Track Mode

Reference page for RHYTHM track mode with five placeholder view sections ready for screenshots, instructions, and notes.

Views

This page covers Track mode. Use the view anchors below to jump directly to the section you want to document.

Track — View 1

Placeholder Track mode screen image for view 1.
Replace this with a real 128x64 screenshot for Track mode, View 1.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Track — View 2

Placeholder Track mode screen image for view 2.
Replace this with a real 128x64 screenshot for Track mode, View 2.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Track — View 3

Placeholder Track mode screen image for view 3.
Replace this with a real 128x64 screenshot for Track mode, View 3.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Track — View 4

Placeholder Track mode screen image for view 4.
Replace this with a real 128x64 screenshot for Track mode, View 4.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Track — View 5

Placeholder Track mode screen image for view 5.
Replace this with a real 128x64 screenshot for Track mode, View 5.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Replace placeholder screen images in the shared images/ folder as real screenshots become available.

Mixer Mode

Reference page for RHYTHM mixer mode with five placeholder view sections ready for screenshots, instructions, and notes.

Views

This page covers Mixer mode. Use the view anchors below to jump directly to the section you want to document.

Mixer — View 1

Placeholder Mixer mode screen image for view 1.
Replace this with a real 128x64 screenshot for Mixer mode, View 1.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Mixer — View 2

Placeholder Mixer mode screen image for view 2.
Replace this with a real 128x64 screenshot for Mixer mode, View 2.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Mixer — View 3

Placeholder Mixer mode screen image for view 3.
Replace this with a real 128x64 screenshot for Mixer mode, View 3.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Mixer — View 4

Placeholder Mixer mode screen image for view 4.
Replace this with a real 128x64 screenshot for Mixer mode, View 4.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Mixer — View 5

Placeholder Mixer mode screen image for view 5.
Replace this with a real 128x64 screenshot for Mixer mode, View 5.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Replace placeholder screen images in the shared images/ folder as real screenshots become available.

Song Mode

Reference page for RHYTHM song mode with five placeholder view sections ready for screenshots, instructions, and notes.

Views

This page covers Song mode. Use the view anchors below to jump directly to the section you want to document.

Song — View 1

Placeholder Song mode screen image for view 1.
Replace this with a real 128x64 screenshot for Song mode, View 1.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Song — View 2

Placeholder Song mode screen image for view 2.
Replace this with a real 128x64 screenshot for Song mode, View 2.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Song — View 3

Placeholder Song mode screen image for view 3.
Replace this with a real 128x64 screenshot for Song mode, View 3.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Song — View 4

Placeholder Song mode screen image for view 4.
Replace this with a real 128x64 screenshot for Song mode, View 4.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Song — View 5

Placeholder Song mode screen image for view 5.
Replace this with a real 128x64 screenshot for Song mode, View 5.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Replace placeholder screen images in the shared images/ folder as real screenshots become available.

Scope Mode

Reference page for RHYTHM scope mode with five placeholder view sections ready for screenshots, instructions, and notes.

Views

This page covers Scope mode. Use the view anchors below to jump directly to the section you want to document.

Scope — View 1

Placeholder Scope mode screen image for view 1.
Replace this with a real 128x64 screenshot for Scope mode, View 1.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Scope — View 2

Placeholder Scope mode screen image for view 2.
Replace this with a real 128x64 screenshot for Scope mode, View 2.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Scope — View 3

Placeholder Scope mode screen image for view 3.
Replace this with a real 128x64 screenshot for Scope mode, View 3.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Scope — View 4

Placeholder Scope mode screen image for view 4.
Replace this with a real 128x64 screenshot for Scope mode, View 4.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Scope — View 5

Placeholder Scope mode screen image for view 5.
Replace this with a real 128x64 screenshot for Scope mode, View 5.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Replace placeholder screen images in the shared images/ folder as real screenshots become available.

Sample Pool Mode

Reference page for RHYTHM sample pool mode with five placeholder view sections ready for screenshots, instructions, and notes.

Views

This page covers Sample Pool mode. Use the view anchors below to jump directly to the section you want to document.

Sample Pool — View 1

Placeholder Sample Pool mode screen image for view 1.
Replace this with a real 128x64 screenshot for Sample Pool mode, View 1.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Sample Pool — View 2

Placeholder Sample Pool mode screen image for view 2.
Replace this with a real 128x64 screenshot for Sample Pool mode, View 2.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Sample Pool — View 3

Placeholder Sample Pool mode screen image for view 3.
Replace this with a real 128x64 screenshot for Sample Pool mode, View 3.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Sample Pool — View 4

Placeholder Sample Pool mode screen image for view 4.
Replace this with a real 128x64 screenshot for Sample Pool mode, View 4.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Sample Pool — View 5

Placeholder Sample Pool mode screen image for view 5.
Replace this with a real 128x64 screenshot for Sample Pool mode, View 5.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Replace placeholder screen images in the shared images/ folder as real screenshots become available.

Calculator Mode

Reference page for RHYTHM calculator mode with five placeholder view sections ready for screenshots, instructions, and notes.

Views

This page covers Calculator mode. Use the view anchors below to jump directly to the section you want to document.

Calculator — View 1

Placeholder Calculator mode screen image for view 1.
Replace this with a real 128x64 screenshot for Calculator mode, View 1.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Calculator — View 2

Placeholder Calculator mode screen image for view 2.
Replace this with a real 128x64 screenshot for Calculator mode, View 2.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Calculator — View 3

Placeholder Calculator mode screen image for view 3.
Replace this with a real 128x64 screenshot for Calculator mode, View 3.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Calculator — View 4

Placeholder Calculator mode screen image for view 4.
Replace this with a real 128x64 screenshot for Calculator mode, View 4.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Calculator — View 5

Placeholder Calculator mode screen image for view 5.
Replace this with a real 128x64 screenshot for Calculator mode, View 5.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Replace placeholder screen images in the shared images/ folder as real screenshots become available.

Settings Mode

Reference page for RHYTHM settings mode with five placeholder view sections ready for screenshots, instructions, and notes.

Views

This page covers Settings mode. Use the view anchors below to jump directly to the section you want to document.

Settings — View 1

Placeholder Settings mode screen image for view 1.
Replace this with a real 128x64 screenshot for Settings mode, View 1.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Settings — View 2

Placeholder Settings mode screen image for view 2.
Replace this with a real 128x64 screenshot for Settings mode, View 2.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Settings — View 3

Placeholder Settings mode screen image for view 3.
Replace this with a real 128x64 screenshot for Settings mode, View 3.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Settings — View 4

Placeholder Settings mode screen image for view 4.
Replace this with a real 128x64 screenshot for Settings mode, View 4.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Settings — View 5

Placeholder Settings mode screen image for view 5.
Replace this with a real 128x64 screenshot for Settings mode, View 5.
Placeholder button map for this view.
Replace with a button/function map for this view.

Use this section to document what this view does, what the user sees, and how the controls behave.

Numbered Steps

  1. Placeholder step for entering or using this view.
  2. Placeholder step for selecting, editing, or confirming values.
  3. Placeholder step for exiting, saving, or moving onward.

Bullet Notes

  • Placeholder note about controls or navigation.
  • Placeholder note about what appears on screen.
  • Placeholder note about common use or behavior.

Replace placeholder screen images in the shared images/ folder as real screenshots become available.
